High Pressure Water Hose
Water Hose
Suction & Delivery Hose
Overview – Totflex Suction & Discharge water hoses are engineered to perform across all levels of pressure and operating conditions required in industrial, construction, agricultural, and municipal water-handling applications. Each product family in this category is built according to the relevant TS EN ISO standards and supplied in 61-meter standard lengths, ensuring uniformity across all hose types.
See the full data sheet for our water hose range below:
Click to view details, download the file, or contact us for more information.
Water Hose – High Pressure
Description – High-pressure rubber water hose produced according to TS EN ISO 1403 Type-3 for 25-bar water transfer in demanding industrial applications.
Technical Specification and Features
Temperature
-20°C | +80°C
Working Pressure
25 Bar / 362.59 psi
Bursting Pressure
75 Bar / 1087.78 psi
ID and OD Range
ID – 1/2″ to 5″ | OD – 5/6″ to 5 5/7″
Flow Medium
Water
Standard / Approval
TS EN ISO 1403 – Type 3
Application
Water connection lines in all industrial sectors where high operating pressure is required.
Technical Specifications and Range of Sizes
Send a Request
Didn’t find exactly what you need?
Check our other hose types and contact us – our team will help you choose the right product for your application.
