Discharge Fuel Hose 10 Bar
Fuel Hose
Suction & Delivery Hose
Overview – Totflex fuel hoses are rubber hoses designed for the transfer of gasoline, diesel, and fuel oil with up to 50% aromatic content, produced in 10-bar and 16-bar versions in delivery, suction–delivery, and corrugated/channeled constructions. All types are supplied in 61-meter lengths and offer consistent performance across a wide size range, with working pressure 10–16 bar and bursting pressure 30–48 bar.
See the full data sheet for our fuel hose range below:
Click to view details, download the file, or contact us for more information.
Fuel Hose – Discharge 10 Bar
Description – Rubber fuel hose used for the transfer of gasoline, diesel and fuel oil where the aromatic content is up to 50%. It is produced for 10-bar working pressure and is suitable for continuous transfer duties in fuel handling systems.
Technical Specification and Features
Temperature
-20°C | +80°C
Working Pressure
10 Bar / 145.03 psi
Bursting Pressure
30 Bar / 435.11 psi
ID and OD Range
ID – 1/2″ to 5″ | OD – 4/5″ to 5 3/5″
Flow Medium
Gasoline, diesel, fuel oil (aroma content 50%).
Standard / Approval
–
Application
Used in fuel transfer operations where gasoline, diesel and fuel oil (aroma content 50%)
Technical Specifications and Range of Sizes
Send a Request
Didn’t find exactly what you need?
Check our other hose types and contact us – our team will help you choose the right product for your application.
